Processor
Processor typeIntel®
Processor family3rd Generation Intel® Xeon® Scalable Processors
Processor number1 or 2
Processor core available16 to 40 core, depending on processor
Processor speed3.1 GHz maximum, depending on processor
Server Memory
Memory typeHPE DDR4 Smart Memory
Maximum memory8.1 TB – RDIMM (4 TB per processor), 11.2 TB – LRDIMM and Intel® Optane™ (5.6 TB per processor with 8x
LRDIMM and 8x 512 GB Intel Optane)
Memory slots32
Memory protection featuresRAS – Advanced ECC, online spare, mirroring, combined channel (lockstep) functionality, and HPE Fast Fault Tolerant Memory (ADDDC); Intel Optane Persistent Memory
NVDIMM typeOptional: Intel® Optane™ Persistent Memory for HPE
NVDIMM capacityOptional: 128 GB – 512 GB
Server Cooling
System fan featuresHot-plug redundant fans, standard
Server Expansions
Expansion slots8, for detailed descriptions refer to the QuickSpecs
Server Form Factor
Form factor2U Rack
Server Controllers
Network controllerIntel I350 1GbE 4 port Base-T OCP3 adapter or Broadcom 57416 10GbE 2 port Base-T adapter and/or optional network adapters depending on model
Storage controllerHPE SR932i-p and/or HPE SR416i-a and/or HPE MR216i-a and/or HPE MR416i-a and/or HPE MR216i-p and/or HPE MR416i-p and/or HPE Smart Array P816i-a SR and/or HPE Smart Array E208i-a SR and/or HPE Smart Array P408i-a SR and/or HPE Smart Array E208i-p SR and/or HPE Smart Array E208e-p SR and/or HPE Smart Array P408e-p SR and/or HPE Smart Array P408i-p SR
Server Drives
Drive supported8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD, 2 M.2 SATA SSD standard on primary riser, depending on configuration, 8 SFF mid-tray optional, 6 SFF rear drive optional or 4 LFF mid tray optional, 3 LFF rear-drive optional and 2 SFF or 2 Dual UFF rear-drive optional, 20 SFF NVMe optional, NVMe support via Express Bay will limit maximum drive capacity, depending on model
Optical drive typeOptional DVD-ROM Optional via Universal Media Bay External support only
Server Power
Power supply typeDual hot-plug redundant 1+1 HPE Flexible Slot Power Supplies (2.6”)
Management Software
Infrastructure managementHPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional, requires licenses)
Security
SecurityOptional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
Warranty
Warranty3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit https://www.hpe.com/support
