Processor
Processor typeIntel?
Processor familyIntel? Xeon? Scalable 8300 series
Intel? Xeon? Scalable 6300 series
Processor number1 or 2
Processor core available8 to 40 core, depending on processor
Processor speed3.6 GHz, maximum depending on processor
Processor cache12 – 60 MB L3, depending on processor
Server Memory
Memory typeHPE DDR4 Smart Memory
Maximum memory6.0 TB per socket, when populated with 256 GB DDR4 and 512 GB Persistent Memory
Memory slots16 DIMM slots per socket
Memory protection featuresHPE Fast Fault Tolerant Memory
Advanced ECC Memory
Online Spare Memory
Mirrored Memory
NVDIMM typeOptional: Intel? Optane? Persistent Memory for HPE
NVDIMM capacityOptional: 128 to 512 GB
Server Expansions
Expansion slotsMaximum 3 PCIe Gen4, for detail descriptions please see QuickSpecs
Server Form Factor
Form factor1U Rack
Server Controllers
Network controllerWide range of speeds, cabling, chipsets and form factors. Please see QuickSpecs for network card choices
Storage controllerIncluded – Embedded SATA controller (AHCI or SR100i modes)
Optional – Variety of protocols -including NVMe-, port count, array utilities, and form factors. Please see QuickSpecs for storage controllers selection
Server Drives
Drive supportedUp to 4 LFF SAS/SATA HDDs or SSDs
Up to 10 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.2 or U.3 SDDs, depending on model
Optical drive typeOptional DVD via Universal Media Bay or USB connectivity
Management Software
Infrastructure managementIncluded – HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download)
Optional – HPE iLO Advanced, and HPE OneView Advanced
Security
SecurityUEFI Secure Boot and Secure Start support
Intel? Software Guard Extensions (SGX) support
Immutable Silicon Root of Trust
Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits
Warranty
Warranty3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit https://www.hpe.com/support
Weights and Dimensions
WeightSFF: 13.04 kg to 16.27 kg
LFF: 13.77 kg to 16.78 kg
SFF: 28.74 lb to 35.86 lb
LFF: 30.36 lb to 37.00 lb
DimensionsSFF: 4.29 x 43.46 x 76.96 cm
LFF: 4.29 x 43.46 x 80.01 cm
SFF: 1.69 x 17.11 x 30.30 in
LFF: 1.69 x 17.11 x 31.50 in
